Specifications

• Frame

  SMOOTHWALL™ Carbon | Penalty Box 2.0 Storage |Full Sealed Cartridge Bearings | Threaded BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-4™ Adjustable Geometry | 160mm Travel | SMOOTHWALL™ Carbon Rear Triangle
• Fork

  Fox 38 Float EVOL GRIP Performance Series 170mm | 27.5 = 37mm Offset | 29 = 44mm Offset
• Front Travel

  170
• Shock

  Fox Float X Performance | Sealed Bearing Eyelet | 40x10mm F Hardware | SM = 210x55mm | MD - LG - XL = 230x60mm | Size-Specific tune in FAQ
• Rear Travel

  160
• Headset

  FSA Orbit NO.85 Reach Adjust | 0mm Cups Installed | +/- 5mm Cups Included | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 6.5mm Upper | 40mm x 51.8mm x 8.0mm Lower | 1.5" Crown Race
• Stem

  Rocky Mountain 35 AM | 0° Rise | All Sizes = 40mm
• Handlebar

  Rocky Mountain AM | 780mm Width | 38mm Rise | 9° Backsweep | 5° Upsweep | 35 Clamp
• Grips

  ODI Elite Pro Lock On
• Brakes

  Shimano XT Trail 4 Piston | Metal Pads
• Shifters

  Shimano SLX
• Rear Derailleur

  Shimano XT
• Cranks & Chainring

  -
• Bottom Bracket

  Shimano Threaded BBMT501-B
• Cassette

  Shimano SLX 10-51T 12spd
• Chain

  Shimano M7100
• Front Hub

  Novatec D791SB Sealed Boost 15mm
• Rear Hub

  DT Swiss 370 Boost 148mm | 18T Star-Ratchet
• Spokes

  DT Swiss Competition 2.0/1.8/2.0
• Rims

  WTB ST i30 TOUGH TCS 2.0 | 32H | Cushcore Trail Tire Inserts | Lightweight | Tire & Rim Protection
• Tires

  Maxxis Assegai 2.5 WT 3C MaxxGrip EXO+ Tubeless Ready | Maxxis Minion DHR II 2.4 WT 3C MaxxTerra DD Tubeless Ready | Cushcore Trail Tire Inserts | Lightweight | Tire & Rim Protection
• Seatpost

  X Fusion Manic Composite 30.9mm | SM = 150mm | MD = 170mm | LG - XL = 200mm
• Saddle

  WTB Solano Fusion Form 142 | Cromoly Rails
• Weight

  35.4 LBS|16 KG
